68 Roadrunner fuel gauge ohms

68RR

Member
Joined
Nov 11, 2021
Messages
5
Reaction score
4
Location
Greenwood, In
Anyone know what the empty and full ohm values are on a 68 roadrunner fuel gauge? I'm wanting to buy a 20 gallon fuel cell with the correct sender ohmic range. Thanks!



Petroleum1

Well-Known Member
Joined
Feb 12, 2022
Messages
94
Reaction score
111
Location
AZ
My factory gas gauge acts a little funky so i bought a Equus 7361 and mounted it under the dash.


Roadcuda

Well-Known Member
Joined
Sep 10, 2008
Messages
10,536
Reaction score
276
Location
Rocky Hill, Ct
My factory gas gauge acts a little funky so i bought a Equus 7361 and mounted it under the dash.
Is it any better with this gauge? The biggest part of this problem is the quality of the aftermarket sending units themself. I've tried 4 or 5 units to get on that was even close to reading correctly. In the end I had to get one of these, https://www.tanksinc.com/index.cfm/...t_id=748/category_id=184/mode=prod/prd748.htm It's an easy to install, and you can adjust the meter to the sending unit levels.


69hemibeep

Sponge Bob Square Wheels
Joined
Sep 10, 2008
Messages
22,141
Reaction score
2,344
Location
AZ Desert,
About the best you can do is adjust it at empty and then write down where its at after a 5 gallon can for a 1/4 then another for a 1/2 and again for 3/4 19 gallon tank it gets you pretty close


Petroleum1

Well-Known Member
Joined
Feb 12, 2022
Messages
94
Reaction score
111
Location
AZ
Interesting unit i just installed the aftermarket gauge and need to top the tank off to see where the needle goes. If its off i will get one of these and try it. thx


68RR

Member
Joined
Nov 11, 2021
Messages
5
Reaction score
4
Location
Greenwood, In
73-10. 10 being full
Thanks for that. I'm looking to get a new 20 gallon 70-10 ohm fuel cell. Some show fittings on top and bottom like mine. Others show both fittings on top. How does that work? Also some have foam, others don't. Is foam recommend?


quikbird

Well-Known Member
Joined
Mar 1, 2014
Messages
3,229
Reaction score
1,020
Location
Sarasota, florida
Foam is an anti slosh material for those racers who do not want the fuel uncovering the pickup either on acceleration and/ or turns
