Which Transmission

Transmission and Drivetrain

  1. Mateya

    Mateya Active Member

    Messages:
    41
    Likes Received:
    Joined:
    Jul 17, 2019
    Location:
    Pittsburgh
    My car originally had a 4 speed. Question is do I keep that or install a 6 speed to make the car more driver friendly. In the end I want my car to be a fun driver and want to be able to have a nice quick start from 0 but also be able to cruise down a highway at 70+ with no problems. I know there are a lot more factors that go into this but wanted to see what other people have done in this case.

  2. 69hemibeep

    69hemibeep Sponge Bob Square Wheels

    Messages:
    20,712
    Likes Received:
    Joined:
    Sep 10, 2008
    Location:
    AZ Desert,
    No cutting with a Gear Vendors Over drive unit and less expensive

    Russ69Runner likes this.
  3. quikbird

    quikbird Well-Known Member

    Messages:
    2,577
    Likes Received:
    Joined:
    Mar 1, 2014
    Location:
    columbus, ohio
    I agree, gear vendor probably would be about half the cost of changing to either a manual 6 speed or a new 6 speed automatic

    Russ69Runner likes this.
  4. Mateya

    Mateya Active Member

    Messages:
    41
    Likes Received:
    Joined:
    Jul 17, 2019
    Location:
    Pittsburgh
    Stupid question but what is gear vendor? I think I found the website but its not very good.

    Russ69Runner likes this.
  5. quikbird

    quikbird Well-Known Member

    Messages:
    2,577
    Likes Received:
    Joined:
    Mar 1, 2014
    Location:
    columbus, ohio
    Gear vendor is a company that makes overdrive transmissions that fit behind your existing tranny and give you the extra gears that let you drive comfortably on the freeway or the drag strip. They are very tough and fairly simple to install.

    Russ69Runner likes this.
  6. Rich B

    Rich B Well-Known Member

    Messages:
    192
    Likes Received:
    Joined:
    Jun 23, 2019
    Location:
    Minot, ME
  7. Russ69Runner

    Russ69Runner Well-Known Member

    Messages:
    4,015
    Likes Received:
    Joined:
    Aug 4, 2016
    Location:
    Lake Wales Fl.
    With the gear vendor you will have to shorten the drive shaft. That is the only change I see you will have to make. Just to say they are not cheap. Think this is the way to go. If you get a 5 speed transmission Their are adjustment's to the tunnel and the shifter sit's more center in the long run to many changes I think. Like Quick bird said they have used them in the X car's and tested the gear vendor's. The hold up well. It works with an Electric switch in side the car. Their is a video of them using it on the highway. To show the difference in the RPM on the motor. But the kicker is the price is up their. :beep:

  8. RKNRLR

    RKNRLR Well-Known Member

    Messages:
    341
    Likes Received:
    Joined:
    Mar 27, 2017
    Location:
    Sydney, Australia
    I like the look and feel of the 4 speed, so I am gonna go the gearvendors OD route. But if you want a little lower revs on the highway, try a slightly taller tire. I dropped about 400rpm @ 70mph by going up to a 275/-60 R15. Been searching for the ghost that is the 285/70 R15 that BFG used to make, will give you 29 inches in a street tire.

    Russ69Runner likes this.
  9. jww69rrpost

    jww69rrpost Member

    Messages:
    13
    Likes Received:
    Joined:
    Jun 27, 2018
    I have a Gear Vendor in my 69 Road Runner. The transmission is a B&M 727 and the setup is fantastic. It is actually referred to as an Under/Overdrive system and is manufactured in El Cajon, California with all USA parts... where you can just use it as a standard overdrive with 1st; 2nd; drive, and overdrive, or switch to manual pushbutton and it goes from 1st, then between 1st and 2nd, then 2nd, then between 2nd and 3rd, then 4th (or overdrive) - it splits the gears resulting is six forward gears and makes for an amazing ET and launch, plus is just plain fun to drive. I also switched from 3.91 rear gears to 3.23 and with this system, the launch is terrific and I can easily cruise at 70(+) and keep it below 3000 rpms - much less stress on the entire drivetrain!!! I also dumped the sure grip for an Eton Detroit Locker Truetrac which is more than amazing, and there is absolutely no maintenance or additives required.

    Russ69Runner likes this.
  10. Russ69Runner

    Russ69Runner Well-Known Member

    Messages:
    4,015
    Likes Received:
    Joined:
    Aug 4, 2016
    Location:
    Lake Wales Fl.
    I am sold on the gear vendor but will be a while before I get one. Question is did you install it or have it done. I have read that the drive shaft has to be shortened. How did the install go was it hard or easy. Thank you for the info. Russ.

  11. RKNRLR

    RKNRLR Well-Known Member

    Messages:
    341
    Likes Received:
    Joined:
    Mar 27, 2017
    Location:
    Sydney, Australia
    Yeah russ, drive shaft will have to be shortened, Im gonna go for a new one though, jsut incase I ever want to go back to stock, or sell the unit. Ive ordered a reco Hemi box from Passon, but he doesnt sound real keen on sending it over, to have the overdrive put on it, even though Im having it done by a pro.

    Russ69Runner likes this.
  12. Russ69Runner

    Russ69Runner Well-Known Member

    Messages:
    4,015
    Likes Received:
    Joined:
    Aug 4, 2016
    Location:
    Lake Wales Fl.
    Sorry to here that on Passon not wanting to send the box. The thing I am wondering about is by shorting the drive shaft what that dose to the U joint declination. I know that they are using them but have not heard of what problem's this may cause. Like I said want to put one in my car at a later date. Passion is making a over drive transmission. Their is a long waiting time for them. So hope you get your transmission and install the gear vendor. Keep us up on if any changes have to be done to body or any thing else other than shorting the drive shaft. Wish you the best want to see it working. Your friend Russ.

  13. 69hemibeep

    69hemibeep Sponge Bob Square Wheels

    Messages:
    20,712
    Likes Received:
    Joined:
    Sep 10, 2008
    Location:
    AZ Desert,
    Passon sells a 4 speed or a kit that changes the ratios making 4th gear an OD also

    Russ69Runner likes this.
  14. Russ69Runner

    Russ69Runner Well-Known Member

    Messages:
    4,015
    Likes Received:
    Joined:
    Aug 4, 2016
    Location:
    Lake Wales Fl.
    Is Brewer's and Passon the same company. When I typed in Brewer's it ended up being Passion so I thought.:(

  15. mac

    mac What ?

    Messages:
    1,379
    Likes Received:
    Joined:
    Sep 11, 2008
    Location:
    lancaster, new york
    Russ69Runner likes this.
  16. Russ69Runner

    Russ69Runner Well-Known Member

    Messages:
    4,015
    Likes Received:
    Joined:
    Aug 4, 2016
    Location:
    Lake Wales Fl.
    Thanks Mac I get sooo confused sometimes with these guy's. I got the kit with seals and synchronizer's from Brewers. Along with bearing's. But like I said got lucky it had already been rebuilt even new shift fork's. I feel lucky for 500 for that transmission was a grate deal. Russ.

  17. RKNRLR

    RKNRLR Well-Known Member

    Messages:
    341
    Likes Received:
    Joined:
    Mar 27, 2017
    Location:
    Sydney, Australia
    Hey Russ, says in the Gearvendors booklet that you may need to "slightly massage" the tunnel in one spot for fitment, and you also require an auto trans crossmember, which does not come with the unit. Only moving to the Hemi box because of the engine upgrades. Lets call it "preventative maintenance". Luckily Ive got a mate who's already said he wants my 23-spline box for his VF valiant. thumbnail_Screenshot_2019-12-13-15-04-25-28.png

    Russ69Runner likes this.
  18. Russ69Runner

    Russ69Runner Well-Known Member

    Messages:
    4,015
    Likes Received:
    Joined:
    Aug 4, 2016
    Location:
    Lake Wales Fl.
    So your saying that you need another cross member to support the gear vendor rite. Man that would be a hart brake having to put another piece of metal under the car's support's. Will have to give that some thought.

  19. 69hemibeep

    69hemibeep Sponge Bob Square Wheels

    Messages:
    20,712
    Likes Received:
    Joined:
    Sep 10, 2008
    Location:
    AZ Desert,
    No you don't, it replaces the tail housing of the transmission and according to the tech people on a B-body the holes on the cross member should be elongated 1/8 inch for the unit to clear the floor

    Russ69Runner likes this.
  20. jww69rrpost

    jww69rrpost Member

    Messages:
    13
    Likes Received:
    Joined:
    Jun 27, 2018
    Very-very slight modifications, no cutting, drilling, or welding of any other pieces and no additional cross members. The driveshaft is shortened, but not that much to be concerned about... does not change anything on the rear gear alignment. I also added an adjustable rear-end rubber snubber and driveshaft loop (just to be safe). The adjustable snubber permits fine tuning of the axle movement (reducing rear twisting), and aids to the launch capabilities. Along with these modifications, I also changed a lot of suspension to significantly upgraded heavy-duty parts; replaced the upper and lower control arms with tubular A-arms and added front and rear anti-sway bars (along with a few other tubular parts)... and switched the K-member for a QA1 tubular setup, and of course subframe connectors (welded in place). The car rides and handles like a high-end sports car... no lean in cornering and drives absolutely straight. I kept the torsion bars (they are upgraded to a more heavy grade) stayed away from coil-overs or rack and pinion... wanted to maintain as much of the original Mopar look as possible. It would have actually been cheaper to go with coil-overs and rack and pinion, but that would have been just a little too much moving away from the funkiness of the undercarriage look.

    Russ69Runner likes this.
